FEATURES:
700 WATT RMS
Digital Bi-amp
DSP Sound Processing
RCF Precision Transducers
131 dB MAX SPL
RCF Precision 3.0″ voice coil compression driver, titanium dome
RCF Precision 12″ woofer
ACOUSTICAL SPECIFICATIONS:
Frequency Response -3 dB:45 Hz ÷ 20000 Hz
Max SPL:131 dB
Horizontal coverage angle:90°
Vertical coverage angle:60°
Compression Driver:2″, 3.0″ voice coil
Woofer:12″, 2.5″ voice coil
INPUT/OUTPUT SECTION:
Input signal:bal/unbal
Input connectors:Jack-XLR male
Output connectors:XLR female
Input sensitivity:-2 dBu / + 4 dBu
PROCESSOR SECTION:
Crossover frequencies:800 Hz
Protections:thermal, RMS
Limiter:soft limiter
Controls:Volume, EQ shape, Mic/line
AMPLIFIER SPECIFICATIONS:
Total power:1400 W PEAK
High frequencies:400 W PEAK
Low frequencies:1000 W PEAK
Total power:700 W RMS
High frequencies:200 W RMS
Low frequencies:500 W RMS
Cooling:convection
Connections:Powercon
CABINET:
Cabinet Material:Composite PP
Hardware:1 x M10 top, 1 x M10 bottom, 3 x M6 bottom
Handles:1 top, 2 side
Pole Mount/Cap:Yes
Grille:Steel
Colour:Black
PHYSICAL SPECIFICATIONS
Height:647/25.47 mm/inch
Width:380/14.96 mm/inch
Depth:380/14.96 mm/inch
Net Weight:18.8/41.44 kg/lbs
